Hastelloy C276 Bolts
ISO Approved Alloy C276 Fasteners Manufacturer in India
Hastelloy C276 Bolt
ASTM B574 UNS N10276 Studs
Nickel C276 Nut
Are You Finding One of the Most Trusted and Affordable Hastelloy C276 Bolts Manufacture in India? Click Here to Contact
Table of Content
- Hastelloy C276 Bolts Specifications
- Types of Hastelloy Alloy C276 Fasteners
- Which Certifications Are provided by KM Steel India for Alloy C22 Bolts ?
- Hastelloy C276 Thread Stud Bolt Dimensions
- Alloy C276 Nut Size Chart
- 2.4819 Hastelloy C276 Socket Head Cap Screws Dimensions
- What factors affect the price of Hastelloy C276 fasteners?
- UNS N10276 Nuts Temperature Range
- Hastelloy C276 Threaded Rod Torque Chart
- ASTM B574 UNS N10276 Bolts Coating’s
- Alloy Hastelloy C276 Stud Bolts Surface Finish
- Heat Treatment of Alloy Hastelloy C276 Washers
- Hastelloy C276 Bolt Nut Physical Properties
- Mechanical Properties of UNS N10276 Screws
- ISO Standards of Hastelloy Alloy C276 Fastener
- DIN Standards of Hastelloy C276 Bolt Nut
- List of Countries Where We Make Frequent Deliveries
- Chemical Composition of Nickel alloy C276 Nuts
- C276 Hastelloy Socket Head Cap Screws Weight
- Hastelloy C276 Anchor Bolts Equivalent Standard
- Hastelloy C276 Hex Bolts Documentation
- Is Haynes Alloy C276 Stud Bolts Magnetic?
- Delivery location and time Schedule for 2.4819 Hastelloy C276 Dowel Pin
- Length Chart Nickel Alloy C22 Anchor Bolts
- Other Names for Hastelloy C276 Fasteners
- Heat Treatments Hastelloy C276 Bolt Nut
- Corrosion Resistance of Weldments in Hastelloy C-276 Fasteners
Nickel C276 Bolt and Nut in Both Metric and Imperial Sizes at Best Price
Hastelloy C276 Bolts Specifications
- Threaded Rod : M4 – M45
- Bolts : M1.2 – M48
- Nut : M2 – M20
- Screw : M1.2 To M48
- UNF
- UNC BSF
- BSW
- METRIC
- Chamfer, Flat
- Sheared
- Saw cut
- Rounded
- High Strength Alloy
- High Temperature Stability
- Superior Corrosion Resistance
- Long Life
- Aerospace fuel membranes
- Reactor vessels
- Petrochemical
- Nuclear reactors
- USA, Dubai
- Oman, Saudi Arabia
- Algeria, South africa
- UAE, Abu Dhabi
- Cold Drawn
- Threading
- Coarse Threads
- Fine Threads
- ASTM B574
- ASME SB574
- UNS: N10276
- Cold Forging
- Hot Forging
- CNC machined
- Flattening
- Creep Testing
- Hardness Testing
- Wedge & Axial Tensile
- Double Shear
- Oxidation
- DACROMET, HDG
- Phosphating
- Electric galvanized
- Zinc impregnation
- Corrugated Box
- Carton
- Small Pack
- Pallet
- Heat number
- Specification
- Material grade
- Custom logo
Types of Hastelloy Alloy C276 Fasteners
Hastelloy Alloy C276 Bolts Supplier in India Provides a Wide Range of The Most Common Types
Nickel Alloy C276 Bolts in Stock
Hastelloy 2.4819 Hex Head Bolt
Hastelloy Alloy C276 Flange Bolts
Alloy C276 Square Head Bolts
ASTM B574 UNS N10276 Eye Bolts
2.4819 Hastelloy C276 J-Bolts
Nickel C276 Flange Bolts
UNS 0276 Hanger Bolts
EN 2.4819 U-Bolts
Alloy Hastelloy C276 Shoulder Bolts
C276 Hastelloy Nuts in Stock
Werkstoff NR. 2.4819 Heavy Hex Nuts
Alloy C276 Hex Jam Nuts
Haynes Alloy C276 Keps-K Lock Nuts
Hastelloy C276 Castle Nuts
Nickel Alloy C276 Cap Nuts
Hastelloy Alloy C276 Alloy Nuts
Alloy Hastelloy C276 Screw in Stock
Nickelvac® HC276 Hex Cap Screws
Alloy Hastelloy C276 Socket Head Cap Screws
Hastelloy 2.4819 Button Head Screws
Nicrofer® 5716 Self Drilling Screws
Haynes Alloy C276 Machine Screws
C276 Hastelloy Wood Screw
Nickel C276 Stud Bolts in Stock
Hastelloy C276 Full Threaded Stud
Nickel Alloy C276 Tap End Stud
Hastelloy 2.4819 Double End Stud
Hastelloy Alloy C276 Threaded Rod
Hastelloy 2.4819 Bolting Stud Bolts
Alloy C276 Weld Studs
ASTM B574 UNS N10276 Washers in Stock
2.4819 Hastelloy C276 Fender Washers
Nickel C276 Square Washers
EN 2.4819 Flat Washers
Alloy Hastelloy C276 Spring Washers
Which Certifications Are provided by KM Steel India for Alloy C22 Bolts ?
- Material Test Certificates (MTC)
- Heat Treatment Charts
- Surface roughness measurement
- Fumigation Certificates
- Third Party Inspection Report
- HS Code Commercial Invoice
- Raw Materials Certificate
- EN 10204/3.1B
Hastelloy C276 Thread Stud Bolt Dimensions
| Nominal Size | Diameter | UNC Threads | Threads Per Inch |
|---|---|---|---|
| Inches | D | Min-Max. (U) | UNC |
| 1 | 1.0000 | 0.125 to 0.250 | 8 |
| 1-3/8 | 1.3750 | 0.167 to 0.333 | 6 |
| 1-1/2 | 1.5000 | 0.167 to 0.333 | 6 |
| 1-3/4 | 1.7500 | 0.200 to 0.400 | 5 |
| 1-1/8 | 1.1250 | 0.143 to 0.286 | 7 |
| 3/8 | 0.3750 | 0.063 to 0.125 | 16 |
| 7/16 | 0.4375 | 0.072 to 0.143 | 14 |
| 1/2 | 0.5000 | 0.077 to 0.154 | 13 |
| 9/16 | 0.5625 | 0.084 to 0.167 | 12 |
| 5/8 | 0.6250 | 0.091 to 0.182 | 11 |
| 3/4 | 0.7500 | 0.100 to 0.200 | 10 |
| 2-3/4 | 2.7500 | 0.250 to 0.500 | 4 |
| 1-1/4 | 1.2500 | 0.143 to 0.286 | 7 |
| 7/8 | 0.8750 | 0.111 to 0.222 | 9 |
| 2 | 2.0000 | 0.222 to 0.444 | 4-1/2 |
| 2-1/4 | 2.2500 | 0.222 to 0.444 | 4-1/2 |
| 2-1/2 | 2.5000 | 0.250 to 0.500 | 4 |
| 1/4 | 0.2500 | 0.050 to 0.100 | 20 |
| 5/16 | 0.3125 | 0.056 to 0.111 | 18 |
| 3 | 3.0000 | 0.250 to 0.500 | 4 |
Alloy C276 Nut Size Chart
| Size | Inch | MM | Nearest (Fraction) |
|---|---|---|---|
| 0 | 0.06 | 1.5 | 1/16 |
| 2 | 0.08 | 2.0 | 3/32 |
| 4 | 0.11 | 2.8 | 7/64 |
| 6 | 0.13 | 3.3 | 9/64 |
| 10 | 0.19 | 4.8 | 3/16 |
| 1 | 0.07 | 1.8 | 5/64 |
| 14 | 0.24 | 6.3 | 1/4 |
| 3 | 0.09 | 2.3 | 7/64 |
| 5 | 0.12 | 3.1 | 1/8 |
| 8 | 0.16 | 4.2 | 5/32 |
| 12 | 0.21 | 5.5 | 7/32 |
2.4819 Hastelloy C276 Socket Head Cap Screws Dimensions
Hastelloy C276 Bolts Supplier in India provides premium-grade fasteners with a Accurate Dimensions Values
| Size of D | Dia of Body | Thick of Head | Bolts Corners Across | Flats Across | ||||
|---|---|---|---|---|---|---|---|---|
| – | D (Min) | D (Max) | H (Min) | H (Max) | C (Min) | C (Max) | F (Min) | F (Max) |
| M100 | 99.13 | 90.00 | 60.10 | 63.9 | 159.60 | 167.43 | 140.00 | 145.00 |
| M90 | 89.13 | 90.00 | 54.26 | 57.74 | 143.07 | 150.11 | 125.50 | 130.00 |
| M80 | 79.26 | 80.00 | 48.42 | 51.58 | 126.54 | 132.72 | 111.00 | 115.00 |
| M72 | 71.26 | 72.00 | 43.55 | 46.45 | 115.60 | 121.24 | 101.40 | 105.00 |
| M64 | 63.26 | 64.00 | 38.68 | 41.32 | 104.65 | 109.70 | 91.80 | 95.00 |
| M56 | 55.26 | 56.00 | 33.80 | 36.2 | 93.71 | 98.15 | 82.20 | 85.00 |
| M48 | 47.38 | 48.00 | 28.93 | 31.07 | 82.76 | 86.60 | 72.60 | 75.00 |
| M42 | 41.38 | 42.00 | 25.03 | 26.97 | 71.71 | 75.06 | 62.90 | 65.00 |
| M36 | 35.61 | 36.00 | 21.63 | 23.38 | 60.79 | 63.51 | 53.80 | 55.00 |
| M30 | 29.67 | 30.00 | 17.92 | 19.48 | 50.85 | 53.12 | 45.00 | 46.00 |
| M24 | 23.67 | 24.00 | 14.56 | 15.44 | 39.55 | 41.57 | 35.00 | 36.00 |
| M20 | 19.67 | 20.00 | 12.12 | 12.88 | 32.95 | 34.64 | 29.16 | 30.00 |
| M16 | 15.73 | 16.00 | 9.68 | 10.32 | 26.75 | 27.71 | 23.67 | 24.00 |
| M14 | 13.73 | 14.00 | 8.51 | 9.09 | 23.35 | 24.25 | 20.67 | 22.00 |
| M12 | 11.73 | 12.00 | 4.24 | 7.76 | 20.03 | 20.78 | 17.73 | 19.00 |
| M10 | 9.78 | 10.00 | 6.17 | 6.63 | 17.77 | 18.48 | 15.73 | 17.00 |
What factors affect the price of Hastelloy C276 fasteners?
Refer ASTM B574 UNS N10276 Nuts Temperature and Torque Chart
UNS N10276 Nuts Temperature Range
- 1500°F
- 815°C
Hastelloy C276 Threaded Rod Torque Chart
| Nominal Dia | Torque ft-lb
(Dry) |
Threads | Torque ft-lb
(Lubricated) |
|---|---|---|---|
| Inches | 4.5-5.2 | Inches | 3.4-3.8 |
| 1/2″ | 40.2-45.3 | 13-20 | 30.1-33.9 |
| 1/4″ | 4.5-5.2 | 20-28 | 3.4-3.8 |
| 1-1/4″ | 597-661 | 7-12 | 447-495 |
| 1-1/2″ | 1039-1169 | 6-12 | 779-876 |
| 1″ | 343-385 | 8-14 | 257-289 |
| 5/16″ | 9.3-10.3 | 18-24 | 7.0-7.7 |
| 3/8″ | 16.5-18.6 | 16-24 | 12.4-14.0 |
| 7/16″ | 26.3-29.4 | 14-20 | 19.8-22.1 |
| 9/16″ | 57.9-64.6 | 12-18 | 43.5-48.5 |
| 5/8″ | 79.9-90.5 | 11-18 | 60.0-67.9 |
| 3/4″ | 142-158 | 10-16 | 107-119 |
| 7/8″ | 228-252 | 9-14 | 172-189 |
ASTM B574 UNS N10276 Bolts Coating’s
- Electro Polished
- Teflon Coating
- Oxidized
- Mirror Buffed
- Hot Dipped Galvanizing
- Epoxy Coating
- Passivation
- Zinc Plating
Ready Stock Of Nickel Alloy C276 Threaded Rod With With HDG, Oxidation, Phosphating Surface Finish
Alloy Hastelloy C276 Stud Bolts Surface Finish
Heat Treatment of Alloy Hastelloy C276 Washers
| Annealed | Hot Forming |
|---|---|
| 2100°F To 2150°F | Between 1600 and 2250°F |
Hastelloy C276 Bolt Nut Physical Properties
Hastelloy C276 Bolts Manufacturer in India Offers Fasteners With Excellent Physical Properties
| Property | Value |
|---|---|
| Density | 8.890 g/m3 |
| Thermal Condc | 19 W/m.K |
| Co-eff of Expansion | 13.4 µm/m/°C |
| Elastic Modulus | 205.5 Gpa |
| Electric Resistivity | 1300 nΩ.m |
Mechanical Properties of UNS N10276 Screws
| Properties | Values |
|---|---|
| Yield Strength | 355 MPa |
| Tensile Strength | 790 MPa |
| Elongation | 40% |
| Melting Point | 2500°F |
Suppliler of WNR 2.4819 Studs in Mumbai and Check Haynes Alloy C276 Hex Bolts Tensile Strength
ISO Standards of Hastelloy Alloy C276 Fastener
| Hastelloy C276 Nuts | ||
|---|---|---|
| ISO Standard | ||
| ISO 5448 | ISO 4161 | ISO 7035 |
| ISO 4035 | ISO 4032 | ISO 8675 |
| Hastelloy C276 Bolts | ||
| ISO Standard | ||
| ISO 4014 | ISO 7379 | ISO 4014 |
| Hastelloy C276 Washers | ||
| ISO Standard | ||
| ISO 7089 | ISO 7090 | ISO 7092 |
| Hastelloy C276 Screws | ||
| ISO Standard | ||
| ISO 4017 | ISO 4029 | ISO 4762 |
DIN Standards of Hastelloy C276 Bolt Nut
| Hastelloy C276 Nuts | ||
|---|---|---|
| DIN Standard | ||
| DIN 1587 | DIN 315 | DIN 439 |
| DIN 6923 | DIN 917 | DIN 934 |
| DIN 935 | DIN 936 | DIN 985 |
| Hastelloy C276 Bolts | ||
| DIN Standard | ||
| DIN 529 | DIN 580 | DIN 444 |
| DIN 6921 | DIN 931 | DIN 478 |
| DIN 3570 | DIN 603 | DIN 976 |
| DIN 975 | DIN 931 | ISO 4014 |
| Hastelloy C276 Washers | ||
| DIN Standard | ||
| DIN 125 | DIN 126 | DIN 128 |
| DIN 1440 | DIN 433 | DIN 436 |
| DIN 6797 | DIN 6916 | DIN 7349 |
| DIN 7980 | DIN 7989 | DIN 9021 |
| Hastelloy C276 Screws | ||
| DIN Standard | ||
| DIN 479 | DIN 7504 | DIN 7984 |
| DIN 908 | DIN 912 | DIN 914 |
| DIN 915 | DIN 916 | DIN 933 |
List of Countries Where We Make Frequent Deliveries
Suplier of Hastelloy C276 Bolts, Supply Hastelloy C276 Nuts & Bolts in Various Countries
| Saudi Arabia | UAE | Oman | Nigeria | South Africa |
| USA | Algeria | Kenya | Angola | Tanzania |
| Ethiopia | Zambia | Ghana | Gabon | Morocco |
| New South Wales | Mozambique | Egypt | Tunisia | – |
Chemical Composition of Nickel alloy C276 Nuts
Hastelloy C276 Bolts Manufacturer in India Provides Accurate Chemical Composition of Fasteners.
|
Carbon 0.010% |
Silicon (Si) 0.08 max% |
Manganese (Mn) 1.00 max% |
Tungsten 2.50% To 3.50% |
|
Sulfur (S) 0.02% |
Chromium (Cr) 20.0% To 22.5% |
Cobalt 2.50% |
Nickel (Ni) 50.15% |
|
Iron (Fe) 4.00 – 7.00% |
C276 Hastelloy Socket Head Cap Screws Weight
| Sizes | M3 | M4 | M5 | M6 | M8 |
|---|---|---|---|---|---|
| Weight | 0.81 (g) | 1.9 (g) | 3.1 (g) | 5.8 (g) | 14 (g) |
Hastelloy C276 Anchor Bolts Equivalent Standard
Hastelloy C276 Bolts Supplier in India offers Fasteners with Equivalent Material Grades.
UNS (American)
UNS N10276
JIS (Japan)
NW 0276
EN (European)
NiMo16Cr15W
Werkstoff No (US)
2.4819
Hastelloy C276 Hex Bolts Documentation
Is Haynes Alloy C276 Stud Bolts Magnetic?
No, Haynes Alloy C276 Stud Bolts is not magnetic.
Delivery location and time Schedule for 2.4819 Hastelloy C276 Dowel Pin
| Export to | Estimated delivery |
|---|---|
| Nigeria | 30 days |
| Germany | 20 days |
| Kazakhstan | 45 to 60 days |
| Bangladesh | 15 days |
| Bhutan | 7 days |
| Nepal | 7 days |
| Poland | 45 days |
| Finland | 45 days |
| Sweden | 45 days |
| Norway | 45 days |
| Vietnam | 10 days |
| Cambodia | 9 days |
Length Chart Nickel Alloy C22 Anchor Bolts
| Size | Thread Length | Hook | Length | Size | Thread Length | Hook | Length |
|---|---|---|---|---|---|---|---|
| 3/8 | 1/2 | 1 | 8 | 3/4 | 4 | 3 | 10 |
| 3/8 | 1/2 | 1 | 6 | 3/4 | 4 | 3 | 16 |
| 3/8 | 1/2 | 1 | 12 | 3/4 | 4 | 3 | 14 |
| 3/8 | 1/2 | 1 | 10 | 3/4 | 4 | 3 | 24 |
| 1/2 | 2 | 1 | 8 | 3/4 | 4 | 3 | 18 |
| 1/2 | 2 | 1 | 6 | 3/4 | 4 | 3 | 36 |
| 1/2 | 2 | 1 | 12 | 3/4 | 4 | 3 | 30 |
| 1/2 | 2 | 1 | 10 | 7/8 | 5 | 3 | 14 |
| 1/2 | 2 | 1 | 16 | 7/8 | 5 | 3 | 12 |
| 1/2 | 2 | 1 | 14 | 7/8 | 5 | 3 | 24 |
| 1/2 | 2 | 1 | 20 | 7/8 | 5 | 3 | 18 |
| 1/2 | 2 | 1 | 18 | 1 | 6 | 3 | 15 |
| 5/8 | 4 | 2 | 6 | 1 | 6 | 3 | 14 |
| 1/2 | 2 | 1 | 24 | 1 | 6 | 3 | 18 |
| 5/8 | 4 | 2 | 10 | 1 | 6 | 3 | 16 |
| 5/8 | 4 | 2 | 8 | 1 | 6 | 3 | 24 |
| 5/8 | 4 | 2 | 14 | 1 | 6 | 3 | 20 |
| 5/8 | 4 | 2 | 12 | 1 | 6 | 3 | 36 |
| 5/8 | 4 | 2 | 20 | 1 | 6 | 3 | 30 |
| 5/8 | 4 | 2 | 18 | 1 1/4 | 6 | 3 | 18 |
| 3/4 | 4 | 3 | 6 | 1 | 6 | 4 | 36 |
| 5/8 | 4 | 2 | 24 | 1 1/4 | 6 | 3 | 24 |
Other Names for Hastelloy C276 Fasteners
| Alloy N10276 | UNS N10276 |
|---|---|
| Hastelloy C-276 | Inconel Alloy C-276 |
| ATI C-276 | Nicrofer 5716 hMoW |
Heat Treatments Hastelloy C276 Bolt Nut
| Hot forming | Heavy forming |
|---|---|
| between 1600 and 2250°F | above 2000°F |
Corrosion Resistance of Weldments in Hastelloy C-276 Fasteners
| Environment | Weld Filler Metal | Base Metal Alloy
(5-6 mm thickness) |
Maximum Pitting Depth of Attack, mm | ||||
|---|---|---|---|---|---|---|---|
| GTAW Process | GMAW Pulsed Process | ||||||
| Weld Metal | Base Metal | Weld Metal | Base Metal | ||||
| Green Death* | INCONEL filler metal C-276 | INCONEL alloy C-276 | 6.2 | 0 | 3.4 | 0 | |
| INCO-WELD filler metal 686CPT | INCONEL alloy C-276 | 0 | 0 | 0 | 0 | ||
| ASTM G48C | INCONEL filler metal C-276 | INCONEL alloy C-276 | 0 | 0 | 0 | 0 | |
| INCO-WELD filler metal 686CPT | INCONEL alloy C-276 | 0 | 0 | 0 | 0 | ||
Why Choose KM Steel India ?
- ISO & PED Approved Manufacturer & Supplier for Fastening Products
- Importer and Exporter of Hex Bolts, Threaded Rod, Studs, Socket Head cap screws in Maharashtra.
- Top 5 Trader & Wholesaler of Set screws, Machine screws, Washers, Heavy Hex head bolt, Double Ended Studs in India, For Low and High Temperature Applications.
- Offer Inexpensive Rates to the local Distributor & Reseller Binondo, Saudi Arabia, Manila, Quezon city, South Africa, UAE, Sharjah, Philippines, Cebu, Penang.
- Stockist of Rivets, Hex Nuts, Lock Nuts, Bolts and Nuts Used in Various Industries and Applications For Fastening and Securing Purposes in Maharashtra.
